Product Details
Elevator Cables provides overall electrical control with long suspension length and mechanical stress. Using standard twisted construction design, small crosstalk of signal transmission Upload and download in high speed transfer.
Material
Conductor material: Copper, Bare Copper
Conductor insulation: HDPE/PE
Outer jacket: PVC/LSZH/TPU
Rip cord: Nylon
 Cat6 Elevator Cable |  Cat6 Elevator Cable Manufacturer |  Cat6 Elevator Cable Suppliers |
Features
Eco-friendly, new materials selected. High-temperature resistance, long service life, Ultra flexibility, wear resistant, anti-aging.
Technical Parameters
Conductor: 0.4-0.56±0.01mm CCA/BC
Insulation: 1.09±0.01mm PE
Construction: UTP
Number of Conductors:8
Cross Material: PP
Operating temperature: -20℃-+75℃
Part No. | Cores×section n×mm2 | The biggest diameter D=mm | Cable weight kg/km |
HXELEVATOR-B | 30×0.75 | 39.2±2×7.8±0.5 | 628.1 |
HXELEVATOR-B | 30×1.0 | 49.2±2×9.8±0.5 | 946.4 |
HXELEVATOR-B | 36×0.75 | 42.8±2×7.8±0.5 | 704.1 |
HXELEVATOR-B | 36×1.0 | 54±2×10.6±0.5 | 1126.4 |
HXELEVATOR-B | 40×0.75 | 50±2×7.8±0.5 | 811.0 |
HXELEVATOR-B | 40×1.0 | 63.2±2×9.8±0.5 | 1226.6 |
HXELEVATOR-B | 42×0.75 | 47.4±2×9.5±0.5 | 912.7 |
HXELEVATOR-B | 42×1.0 | 55.6±2×11.7±0.5 | 1288.2 |
HXELEVATOR-B | 48×0.75 | 54.8±2×8.4±0.5 | 961.6 |
HXELEVATOR-B | 48×1.0 | 69.6±2×10.6±0.5 | 1463.7 |
HXELEVATOR-B | 60×0.75 | 66.8±2×8.4±0.5 | 1180.6 |
HXELEVATOR-B | 60×1.0 | 85.2±2×10.6±0.5 | 1801.0 |
Application
Applicable to video transmission and signal control of elevator network system.
